我们可根据任意引线数量、引线宽度和引线间距供应每款产品。其中的一些插座产品包括紧凑外形、强电流触点和可互换插件。

“Contactor” (8500-X-X) & “Carrier” (8000-X-X) 必须单独购买

有关下文所列产品的更多信息，请点击缩略图进入目录页。

欲与我们的团队成员沟通，请联系我们或请求报价.




“Contactor & Carrier” 动画片



“Carrierless” 动画片




 Quad Flat Pack - Carrier and Contactor

8500-025-196-1T
8500-025-196-1T
8500-635mm-84TM
8500-635mm-84TM
6155T
6155T
8500-050-24T
8500-050-24T
8500-635mm-128RT
8500-635mm-128RT
8500-025-106RT
8500-025-106RT
8500-65mm-52ATM
8500-65mm-52ATM

Quad Flat Pack - Carrierless

63076TM
63076TM
5274LR-53-30
5274LR-53-30
6224LR-53-32TM
6224LR-53-32TM
63114-040-48TM
63114-040-48TM
63200-50mm-48T
63200-50mm-48T
63040-840-4
63040-840-4
Lead Count Pitch [mm] Leads Per Side Package Size Carrier Part Number Contactor Part Number
6 - 8 0.040 [1.02] 3 x 4 0.360 [9.14] x 0.480 [12.19] ~ 63086
12 0.050 [1.27] / Variable 1 x 5 0.400[10.16] x 0.555 [14.10] ~ 63077
16 0.105 [2.67] / 0.153 [3.89] 3 x 5 0.590 [14.99] x 1.070 [27.18] ~ 63076
18 - 22 0.050 [1.27] 4 x 7 0.590 [14.99] x 0.622 [15.80] ~ 63073
24 0.050 [1.27] 6 0.390 [9.91] 8000 - 050 - 24T 8500 - 050 - 24T
24 0.050 [1.27] 6 0.390  [9.91] 8000 - 050 - 24T 8500 - 050 - 24T
24 0.050 [1.27] 6 0.390 [9.91] 8000 - 65mm - 24 8500 - 65mm - 24ATM
28 0.027 [0.70] 7 0.262 [6.65] 8100 - 70mm - 28T 8150 - 70mm - 28T
32 0.0256 [0.65] 8 0.390 [9.91] 8000 - 65mm - 32T 8500 - 65mm - 32T
32 0.0256 [0.65] 8 0.390 [9.91] 8000 - 65mm - 32 8500 - 65mm - 32ATM
32 0.030 [0.76] 8 0.550 [13.97] 8000 - 030 - 32 8500 - 030 - 32
40 0.040 [1.02] 10 0.730 [18.54] 8000 - 040 - 40 8500 - 040 - 40
40 0.050 [1.27] 10 1.510 [38.35] 8000 - 050 - 40T 8500 - 050 - 40T
44 0.0256 [0.65] 11 0.500 [12.70] 8000 - 65mm - 44T 8500 - 65mm - 44T
44 0.0394 [1.00] 11 0.730 [18.54] 8000 - 1.00mm - 44 8500 - 1.00mm - 44
44 0.050 [1.27] 11 1.050 [6.67] 8000 - 050 - 44 6155 - 5
44 0.050 [1.27] 11 0.780 [19.81] 8000 - 050 - 44 - 1T 8500 - 050 - 44 - 1T
52 0.0256 [0.65] 13 0.390 [9.91] 8000 - 65mm - 52 8500 - 65mm - 52
52 0.0256 [0.65] 13 0.390 [9.91] 8000 - 65mm - 52 8500 - 65mm - 52ATM
52 0.040 [1.02] 13 0.620 [15.75] 8000 - 040 - 52 8500 - 040 - 52
52 0.050 [1.27] 13 1.050 [6.67] 8000 - 050 - 52 8500 - 050 - 52
54 0.0315 [0.80] 27 0.402 [10.20] x .890 [22.60] ~ 63035
56 0.050 [1.27] 10 x 18 0.800 [20.32] x 1.050 [26.67] 8000 - 050 - 56 8500 - 050 - 56
56 0.050 [1.27] 14 1.220 [30.99] 8000 - 050 - 56A 8500 - 050 - 56A
64 0.0197 [.50] 16 0.394 [10.00] 8000 - 50mm - 64T 8500 - 50mm - 64T
64 0.025 [0.635] 16 0.600 [15.24] 8000 - 025 - 64 8500 - 025 - 64
64 0.0256 [0.65] 16 0.600 [15.24]. 8000 - 65mm - 64T 8500 - 65mm - 64T
64 0.0315 [0.80] 16 0.600 [15.24] 8000 - 80 - 64 8500 - 80 - 64
64 0.040 [1.02] 16 0.600 [15.24] 8000 - 1.016mm - 64T 8500 - 1.016mm - 64T
64 0.050 [1.27] 16 1.000 [25.40] 8000 - 050 - 64 8500 - 050 - 64
66 0.0256 [0.65] 33 0.402 [10.20] x 0.890 [22.60] ~ 63036
68 0.050 [1.27] 17 1.000 [25.40] ~ 63114
68 0.050 [1.27] 17 1.500 [38.10] 8000 - 050 - 68 8500 - 050 - 68
68 0.050 [1.27] 17 1.670 [42.42] 8000 - 050 - 68 - 1 8500 - 050 - 68 - 1
68 0.050 [1.27] 17 1.110 [28.19] ~ 63114 - 9T
80 0.040 [1.02] 20 1.000 [25.40] ~ 63114 - 4T
80 0.050 [1.27] 20 1.500 [38.10] 8000 - 050 - 80 8500 - 050 - 80
82 0.050 [1.27] 20 x 21 1.500 [38.10] 8000 - 050 - 82 8500 - 050 - 82
84 0.025 [0.635] 21 1.010 [25.65] 8000 - 635mm - 84 8500 - 635mm - 84
84 0.040 [1.02] 21 1.040 [26.42]  8000 - 040 - 84 8500 - 040 - 84
84 0.050 [1.27] 21 1.500 [38.10] 8000 - 050 - 84 8500 - 050 - 84
64 0.0197 [.50] 16 0.394 [10.00] 8000 - 50mm - 88T 8500 - 50mm - 88T
96 0.050 [1.27] 24 1.680 [42.67] 8000 - 050 - 96 8500 - 050 - 96
96 0.050 [1.27] 24 1.500 [38.10] 8000 - 050 - 96A 8500 - 050 - 96A
100 0.0197 [0.50] 25 0.770 [19.56] 8000 - 50mm - 100T 8500 - 50mm - 100T
64 0.0197 [.50] 16 0.394 [10.00] 8000 - 50mm - 100 - 1T 8500 - 50mm - 100 - 1T
100 0.020 [0.51] 25 0.460 [11.68] 8000 - 020 - 100 8500 - 020 - 100
100 0.025 [0.635] 25 1.000 [25.40] 8000 - 025 - 100T 8500 - 025 - 100T
100 0.025 [0.635] 25 1.000 [25.40] 8000 - 025 - 100 - 4TM 8500 - 025 - 100 - 4TM
100 0.025 [0.635] 25 1.080 [27.43] 8000 - 635mm - 100T 8500 - 635mm - 100T
100 0.025 [0.635] 25 1.330 [33.78] 8000 - 025 - 100 - 3T 8500 - 025 - 100 - 3T
100 0.050 [1.27] 25 1.500 [38.10] 8000 - 050 - 100 8500 - 050 - 100
100 0.050 [1.27] 25 1.370 [34.80] 8000 - 050 - 100R 8500 - 050 - 100R
106 0.025 [0.635] 19 x 34 0.700 [17.78] x 1.170 [29.72] 8000 - 025 - 106RT 8500 - 025 - 106RT
112 0.050 [1.27] 20 x 36 1.280 [32.51] x 2.080 [52.83] 8000 - 050 - 112 8500 - 050 - 112
128 0.0197 [0.50] 32 0.880 [22.35] ~ 63166T
128 0.025 [0.635] 23 x 41 0.700 [17.78] x 1.170 [29.72] 8000 - 635mm - 128RT 8500 - 635mm - 128RT
128 0.025 [0.635] 23 x 41 0.700 [17.78] x 1.170 [29.72] 8000 - 635mm - 128 - 1RT 8500 - 635mm - 128RT
132 0.025 [0.635] 33 0.875 [22.22] ~ 63146
132 0.025 [0.635] 33 1.040 [26.42] 6154A (132) 6155
132 0.025 [0.635] 33 1.500 [38.10] 8000 - 025 - 132 8500 - 025 - 132
132 0.025 [0.635] 33 1.000 [25.40] 8000 - 025 - 132 - 2 8500 - 025 - 132 - 2
132 0.025 [0.635] 33 0.940 [23.88] 8000 - 025 - 132 - 3T 8500 - 025 - 132 - 3T
132 0.040 [1.02] 33 1.800 [45.72] 8000 - 040 - 132 8500 - 040 - 132
132 0.060 [1.52] 33 2.360 [59.94] ~ 63114 - 7TM
140 0.025 [0.635] 35 1.680 [42.67] 8000 - 025 - 140 8500 - 025 - 140
144 0.025 [0.635] 36 1.500 [38.10]  8000 - 025 - 144 8500 - 025 - 144
160 0.0256 [0.65] 40 1.102 [28.00] 8000 - 65mm - 160T 8500 - 65mm - 160T
164 0.025 [0.635] 41 1.500 [38.10] 8000 - 025 - 164 8500 - 025 - 164
164 0.025 [0.635] 41 1.120 [28.45] 8000 - 025 - 164 - 2 8500 - 025 - 164 - 2
172 0.025 [0.635] 43 1.500 [38.10] 8000 - 025 - 172 - 1 8500 - 025 - 172 - 1
172 0.025 [0.635] 43 1.500 [38.10] 8000 - 025 - 172 - 5 8500 - 025 - 172 - 5
172 0.025 [0.635] 43 1.160 [29.46] 8000 - 025 - 172 - 9T 8500 - 025 - 172 - 2A
176 0.0197 [0.50] 44 1.050 [26.67] 8000 - 50mm - 176T 8500 - 50mm - 176T
180 0.025 [0.635] 45 1.230 [31.24] 8000 - 025 - 180 - 2 8500 - 025 - 180 - 2
180 0.030 [0.76] 36 x 54 1.210 [30.73] x 1.750 [44.45] 8000 - 030 - 180 8500 - 030 - 180
196 0.025 [0.635] 49 1.500 [38.10] 8000 - 025 - 196 - 1 8500 - 025 - 196 - 1
196 0.025 [0.635] 49 1.450 [36.83] 8000 - 025 - 196 - 2D 8500 - 025 - 196 - 2D
196 0.025 [0.635] 49 1.650 [41.91] 8000 - 025 - 196 - 1FT 8500 - 025 - 196 - 1FT
200 0.0315 [0.80] 50 2.730 [69.34] 8000 - 80mm - 200 8500 - 80mm - 200
208 0.0197 [0.50] 52 1.152 [29.26] 8000 - 50 - 208T 8500 - 50 - 208TM
220 0.025 [0.635] 55 1.510 [38.35] 8000 - 635mm - 220T 8500 - 635mm - 220T
224 0.025 [0.635] 56 1.680 [42.67] 8000 - 025 - 224 - 2 8500 - 025 - 224 - 2
240 0.0197 [0.50] 60 1.500 [38.10] 8000 - 50mm - 240T 8500 - 50mm - 240T
240 0.025 [0.635] 60 1.560 [39.62] 8000 - 025 - 240 8500 - 025 - 240
256 0.0197 [0.50] 64 1.800 [45.72] 8000 - 50mm - 256 8500 - 50mm - 256
256 0.020 [0.51] 64 1.900 [48.26] 8000 - 020 - 256 - 1 8500 - 020 - 256 - 1
256 0.020 [0.51] 64 1.900 [48.26] 8000 - 020 - 256 - 3 8500 - 020 - 256 - 3
256 0.030 [0.76] 64 1.900 [48.26] 8000 - 030 - 256 - 1 8500 - 030 - 256 - 1
260 0.0315 [0.80] 65 2.730 [69.34] 8000 - 80mm - 260 8500 - 80mm - 260
268 0.025 [0.635] 54 x 80 1.640 [41.65] x 2.290 [58.17] 8000 - 025 - 268 8500 - 025 - 268
274 0.025 [0.635] 50 x 87 1.620 [41.15] x 2.550 [64.77] 8000 - 025 - 274 - 2T 8500 - 025 - 274 - 2T
274 0.025 [0.635] 50 x 87

1.620 [41.15] x 2.550 [64.77]

 8000 - 025 - 274 - 3T 8500 - 025 - 274 - 3T
280 0.0315 [0.80] 70 2.730 [69.34]  8000 - 80mm - 280 8500 - 80mm - 280
296 0.0256 [0.65] 74 2.570 [65.28] ~ 6346 - 1
298 0.035 [0.89] 63 x 86 2.080 [52.83] x 2.880 [73.15] 8000 - 035 - 298 8500 - 035 - 298
300 0.0315 [0.80] 75 2.730 [69.34] 8000 - 80mm - 300 8500 - 80mm - 300
304 0.0197 [0.50] 76 1.800 [45.72] 8000 - 50 - 304 8500 - 50 - 304
304 0.020 [0.51] 76 1.800 [45.72] 8000 - 020 - 304 - 1 8500 - 020 - 304 - 1
320 0.0197 [0.50] 80 1.749 [44.42] 8000 - 50 - 320T 8500 - 50 - 320T
320 0.0256 [0.65] 80 2.570 [65.28] ~ 6346 - 2
344 0.0256 [0.65] 86 2.570 [65.28] ~ 6346 - 3
352 0.0197 [0.50] 88 1.909 [48.49] 8000 - 50 - 352T 8500 - 50 - 352T
368 0.0256 [0.65] 92 2.570 [65.28] ~ 6346 - 4
368 0.030 [0.76] 59 x 125 2.050 [52.07] x 4.050 [102.87] 8000 - 030 - 368 8500 - 030 - 368
392 0.0256 [0.65] 98 2.570 [65.28] ~ 6346 - 5
408 0.025 [0.635] 102 2.930 [74.42] 8000 - 025 - 408 8500 - 025 - 408
442 0.025 [0.635] 71 x 150 2.050 [52.07] x 4.050 [102.87] 8000 - 025 - 442 8500 - 025 - 442
840 0.050 [1.27] 133 / 287 2.145 [54.48] x 4.145 [105.28] ~ 63040 - 840 - 4
Variable 0.025 [0.635] ~ ~ ~ 5274LR - 25 Series
Variable 0.025 [0.635] ~ ~ ~ 6224LR - 25 Series
Variable 0.030 [0.76] ~ ~ ~ 5274LR - 030 Series
Variable 0.030 [0.76] ~ ~ ~ 6224LR - 030 Series
Variable 0.0315 [0.80] ~ ~ ~ 5274LR - 80mm Series
Variable 0.0315 [0.80] ~ ~ ~ 6224LR - 80mm Series
Variable 0.036 [0.925] ~ ~ ~ 5274LR - 925mm Series
Variable 0.036 [0.925] ~ ~ ~ 6224LR - 925mm Series
Variable 0.0394 [1.00] ~ ~ ~ 5274LR - 1.00mm Series
Variable 0.0394 [1.00] ~ ~ ~ 6224LR - 1.00mm Series
Variable 0.040 [1.02] ~ ~ ~ 5274LR - 58 Series
Variable 0.040 [1.02] ~ ~ ~ 6224LR - 58 Series
Variable 0.040 [1.02] ~ ~ ~ 5274LR - 040 Series
Variable 0.040 [1.02] ~ ~ ~ 6224LR - 040 Series
Variable 0.047 [1.20] ~ ~ ~ 5274LR - 1.20mm Series
Variable 0.047 [1.20] ~ ~ ~ 6224LR - 1.20mm Series
Variable 0.050 [1.27] ~ ~ ~ 5274LR - 53 Series
Variable 0.050 [1.27] ~ ~ ~ 6224LR - 53 Series
Variable 0.090 [2.29] ~ ~ ~ 5274LR - 090 Series
Variable 0.090 [2.29] ~ ~ ~ 6224LR - 090 Series
Variable 0.100 [2.54] ~ ~ ~ 5274LR - 100 Series
Variable 0.100 [2.54] ~ ~ ~ 6224LR - 100 Series
Variable 0.125 [3.18] ~ ~ ~ 5274LR - 125 Series
Variable 0.125 [3.18] ~ ~ ~ 6224LR - 125 Series
